General specifications | ||
---|---|---|
Switching function | Normally open/closed (NO/NC) | |
Rated operating distance | 40 mm | |
Installation | non-flush | |
Output polarity | AC/DC | |
Assured operating distance | 0 ... 32.4 mm | |
Reduction factor rAl | 0.45 | |
Reduction factor rCu | 0.45 | |
Reduction factor r304 | 0.8 | |
Nominal ratings | ||
Operating voltage | 20 ... 253 V | |
Operating voltage DC | 20 ... 300 V | |
Switching frequency | 0 ... 25 Hz | |
Hysteresis | typ. 3 % | |
Short-circuit protection | pulsing | |
Voltage drop | ≤ 4 V | |
Momentary current (20 ms, 0.1 Hz) |
0 ... 3000 mA | |
Operating current | 5 ... 500 mA | |
Off-state current | 0 ... 2.5 mA typ. 1.5 mA | |
Operating voltage indicator | LED, green | |
Switching state indicator | LED, yellow | |
Standard conformity | ||
Standards | IEC / EN 60947-5-2:2004 | |
Approvals and certificates | ||
CCC approval | Certified by China Compulsory Certification (CCC) | |
Ambient conditions | ||
Ambient temperature | -25 ... 70 °C (-13 ... 158 °F) | |
Mechanical specifications | ||
Core cross-section | up to 2.5 mm2 | |
Housing material | PBT | |
Sensing face | PBT | |
Degree of protection | IP68 |
